Designed by Stellar RF Technology, this MK-connector HF handheld antenna is specifically engineered for compatible Motorola portable two-way radios and demanding field applications. Its reinforced flexible whip incorporates a spring-loaded midsection that allows the antenna to flex under impact, helping improve break resistance during hunting, outdoor work, and use in rough environments. The rugged design is built to withstand repeated bending and accidental knocks while maintaining a secure connection and dependable RF performance. Custom frequency tuning is available to match specific operating requirements, making this antenna well suited for professional, commercial, industrial, hunting, and other rugged communication applications.
MK HF 31 MHz Break-Resistant
Key Feature
MK Connector for Compatible Motorola Handheld Radios
HF Tuned Handheld Antenna
Custom-Tuned Frequencies Available
Spring-Loaded Midsection for Added Flexibility
Break-Resistant Design for Rugged Field Use
Flexible Whip Construction for Portable Radios
50 Ω Nominal Impedance
Built for Hunting, Outdoor & Harsh Environments
Ideal for Commercial, Industrial, Professional Radio Applications
Frequency Range:
HF 27-39 MHz, custom-tuned frequencies available
Impedance:
50 Ohm
VSWR:
≤ 1.5:1 at tuned center frequency
Gain:
1.8 dBi
Maximum Power:
Supports up to 25 Watts
Polarization:
Vertical
Radiation Pattern:
360° Omnidirectional
Connector:
MK (Motorola Spec)
Antenna Length:
20 inch
Antenna Type:
Flexible VHF Handheld Whip Antenna
Construction:
Spring-Loaded Midsection Break-Resistant, impact-resistant whip construction for portable radio use
Mounting:
Direct connection to compatible handheld two-way radios
Frequency Tuning:
Available with custom HF frequency tuning to meet specific radio and communication requirements
Application:
Hunting, Outdoor, Industrial, Search & Rescue, and Other Rugged Motorola Handheld Radio Applications.
